Stainless steel spray dryer (centrifugal spray dryer/high-speed centrifugal spray dryer) is mainly used in universities, research institutes and laboratories of food, medicine and chemical companies to produce micro-particle powders, and has broad-spectrum applications for all solutions such as emulsions and suspensions. It is suitable for drying heat-sensitive materials such as biological products, biological pesticides, enzyme preparations, etc., because the sprayed materials are only exposed to high temperature when sprayed into mist-like particles, so they are only heated instantly to maintain these activities After the material is dried, its active ingredients remain undamaged.

Product use:

Food, pharmaceuticals, milk powder, egg yolk, soy sauce, coffee, starch, protein, hormones, serum, antibiotics, enzymes, spices, extracts, organic chemistry

Inorganic chemical fields such as wax, dyes, detergents, surfactants, pesticides, preservatives, synthetic resins, pigments, etc.

Ferrites, ceramics, powders for copying, magnetic materials, metal powders, photosensitive materials, various industrial chemicals, sample waste liquids and other fuel cell development fields for automobiles and ships

Main features:

●Original centrifugal nozzle, high efficiency (two-fluid nozzle can be used, or it can be customized into a centrifugal and two-fluid combo)

●The feed volume can be adjusted by the feed peristaltic pump, and the small sample volume can reach 50ml.

●The finished dry powder after drying has a relatively uniform particle size, and more than 95% of the dry powder is in the same particle size range.

●The drying speed is fast, 95-98% of the water can be evaporated in an instant, and it takes more than ten seconds to complete the drying.

●Using parallel-flow spray drying, the temperature of the droplets is not high during the drying process, and the product quality is good.

●According to the physical properties of the material, it can be dried with hot air or cold air.

●Because the drying process is completed in an instant, the particles of the product can basically maintain the approximate spherical shape of the droplets, and the product has good dispersibility, fluidity and solubility.

●Simplified production process and convenient operation and control. Spray drying is usually used for solvents with a moisture content of 40-60%. Even if the moisture content is as high as 90%, special materials can be dried into powder products at one time.

●In order to prevent the material from being polluted and prolong the life of the equipment, all parts in contact with the material are made of 1Cr18Ni9Ti stainless steel.

●The whole body is made of mirror stainless steel to prevent wall deformation and corrosion.

●It is equipped with a sample observation window, which is safe and intuitive.

Technical parameters:

◆Color large touch screen operation, combination of automatic control and manual control, Chinese and English panel, parameter LCD display.

◆Real-time control PID constant temperature control technology, accurate temperature control, heating temperature control accuracy ±1℃.

◆The spray, drying and collection device is made of high-quality 304 stainless steel with double mirrors, and the spray drying chamber is equipped with an observation port.

◆The atomization structure of the centrifugal spray, the particle diameter of the spray powder is normally distributed, and the fluidity is good.

◆The feed volume can be adjusted by the feed peristaltic pump.

◆Special protection function, the fan can't start, the heater can't start.

◆Equipped with air inlet filter to ensure the purity of the sample.

◆The dried product has uniform particle size, and more than 95% of the dry powder is in the same particle size.

◆Inlet air temperature control: 30 ℃ ～300℃

◆Exhaust air temperature control: 30 ℃ ～140℃

◆Centrifugal nozzle: 2000-40000 rpm (adjustable)

Spray dryer TECHNICAL PARAMETERS  spray dryer
