The three-dimensional motion mixer is a kind of mixer, which is used for the high uniformity mixing of powder and granular materials in the pharmaceutical, chemical, food, light industry, electronics, machinery, mining and metallurgy, national defense industry, and scientific research units. The arc transition mixing rate is over 99.9%, and it has been precision polished.

Principle

During the operation of the three-dimensional motion mixer, due to the multi-directional operation of the mixing barrel, the flow and diffusion of various materials are accelerated during the mixing process, and at the same time, the specific gravity segregation and segregation of materials caused by the centrifugal force of the general mixer are avoided. Accumulation phenomenon, mixing without dead ends, can effectively ensure the best quality of the mixture.

Structure

The three-dimensional motion mixer is composed of a base, a transmission system, an electrical control system, a multi-directional motion mechanism, a mixing barrel and other components. The mixing barrel directly in contact with the material is made of stainless steel, and the inner and outer walls of the barrel are polished.

Features

· The mixing barrel of the machine moves in multiple directions, the material has no centrifugal force, no specific gravity segregation, stratification, and accumulation. Each component can have a large difference in weight ratio, and the mixing rate is more than 99.9%. It is one of the various mixers. Kind of ideal product.

· The barrel body has a large charging rate, up to 90% (only 40% for ordinary mixers), high efficiency and short mixing time.

Application

The three-dimensional swing mixer series is a kind of aseptic, dust-free, fully enclosed high-efficiency and energy-saving powder mixer. It uses the unique three-degree swing, translational rotation and rock and roll principle to generate a strong alternating pulse motion to continuously push the mixed materials. The vortex generated by it has a varying energy gradient, which can achieve the mixing effect, and even Several materials of different specific gravity and different particle sizes can also be mixed quickly and uniformly

The three-dimensional motion mixer is widely used in the pharmaceutical, chemical, food, metallurgical, light industry and various scientific research units and institutes. It can mix powder and granular materials with good fluidity very uniformly, so that the mixed materials can reach The best mixed state.
