ansportation, and the material is discharged. The dust is filtered by the dust collector through a cloth bag or a filter cartridge. Recycling, there is no dust in the production process, and can improve the utilization rate of materials and reduce enterprise costs.
Scope of application
This machine is widely used in pharmacy, chemical industry, food (for example: Chinese medicine, food, chemical industry, health care, roots, diameter, corn, rice, pepper, pepper, oil wheat, soybean, garlic, star anise, cinnamon, dehydrated vegetables, hawthorn, Dried ginger, sugar, saccharin, grains, dried shrimp skin, pumpkin powder, seasoning) and other industrial materials are crushed.
Model | WFJ-15 | WFJ-20 | WFJ-30 | WFJ-60 |
capacity(Kg/h) | 10-150 | 15-200 | 50-600 | 100-1200 |
Feed size(mm) | <8 | <10 | <12 | <15 |
Discharge size(mesh) | 80-400 | 80-400 | 80-400 | 80-400 |
Power(kw) | 13.5 | 21 | 46 | 84 |
Speed(r/min) | 6000 | 5400 | 3800 | 2900 |
Size(mm) | 4000*1400*2700 | 4700*1400*2800 | 6700*1600*3200 | 7500*2000*3400 |
Weight(kg) | 1100 | 1400 | 2300 | 3800 |
